Permian Pump & Valve — Management System

Overdue

4

valves past inspection date

Due This Month

3

within 30 days

Total Positions

142

across 6 customer sites

Work Orders YTD

38

last: Aug 05, 2025

Recent Work Orders

View all →

Tag #	Customer	Location	Type	Date	Status
PCU-PC 0317	ExxonMobil	Exxon Baytown Complex	Pretest/Repair	Aug 05	Complete
V-302	ExxonMobil	Exxon Hogan 1-24H	Test Only	Nov 06	Complete
V-486	ExxonMobil	Exxon Bridgewater A	Pretest/Reset	Nov 06	Pending
V-497	ExxonMobil	Exxon Bridgewater A	Repair	Nov 06	Complete
V-201	ExxonMobil	Exxon Hogan 1-24H	Repair	Nov 06	Complete

Urgent Attention

⚠

D-111 · ExxonMobil Baytown

Anderson Greenwood 42310L34/S

+47d

⚠

V-493 · Exxon Hogan 1-24H

Farris 26KA10-120

+23d

◔

V-484 · Exxon Bridgewater A

Mercer 9185J11P98U1

12d

◔

V-495 · Exxon Bridgewater A

Mercer 9153H11T84U1

18d

Filter by › ›

► ExxonMobil Chemical 3 locations · 21 positions 2 overdue 3 due soon

► Exxon Baytown 1 position

Tag #	Valve Position / Equipment	Current Valve	Type	Serial #	Set Press.	Orifice	Last Inspected	Status
PCU-PC 0317	D-111 PCU unit	Anderson Greenwood 42310L34/S	Pilot	90123057	306 PSIG	L	Aug 23, 2021	Overdue

► Exxon Hogan 1-24H 7 positions

Tag #	Valve Position / Equipment	Current Valve	Type	Serial #	Set Press.	Orifice	Last Inspected	Status
V-302	V-302 —	Taylor 825J5711311	Conv.	134598-3	125 PSIG	J	Nov 06, 2025	Current
V-301	V-301 —	Taylor 825J5711311	Conv.	134598-4	125 PSIG	J	Nov 06, 2025	Current
V-493	V-493 —	Ari Reyco R-10KS120CKC0125	Conv.	282252-20	125 PSIG	K	Mar 12, 2024	Overdue
V-201	V-201 —	Ari Reyco R-10KS120CKC0125	Conv.	282252-19	125 PSIG	K	Nov 06, 2025	Current
V-202	V-202 —	Ari Reyco R-10KS120CKC0125	Conv.	286083-02	250 PSIG	K	Jan 05, 2024	Overdue
V-497	V-497 —	Ari Reyco R-10MS120CKC0250	Conv.	262099-06	250 PSIG	M	Nov 06, 2025	Current

► Exxon Bridgewater A 38-25H 8 positions

Tag #	Valve Position / Equipment	Current Valve	Type	Serial #	Set Press.	Orifice	Last Inspected	Status
V-497	Horz Flare V-497	Taylor 825G485131140	Conv.	118828-8	125 PSIG	G	Nov 06, 2025	Current
V-486	Fuel V-486	Mercer 9162J11T84U1	Conv.	1310621	250 PSIG	J	Nov 06, 2025	Current
V-484	Discharge V-484	Mercer 9185J11P98U1	Conv.	1262069	1440 PSIG	J	Dec 01, 2024	Due Soon
V-495	Recycle V-495	Mercer 9153H11T84U1	Conv.	1781159	650 PSIG	H	Dec 10, 2024	Due Soon
V-494	Discharge V-494	Mercer 9144F11P25C1	Conv.	1218512	1440 PSIG	F	Dec 20, 2024	Due Soon
V-483	Inlet V-483	Ari Reyco R10LS120CKC0250	Conv.	285975-02	250 PSIG	L	Nov 06, 2025	Current

► Exxon Natural Resources 1 location · 6 positions All current

Tag #	Valve Position	Current Valve	Type	Serial #	Set Press.	Last Inspected	Status
MB-PSV-001	Separator Inlet	Farris 2600 Series	Conv.	F-44821	300 PSIG	Jan 14, 2025	Current
MB-PSV-002	Compressor Discharge	Farris 2600 Series	Conv.	F-44822	1200 PSIG	Jan 14, 2025	Current

Add Valve to Position

Register a new valve asset at an existing position. This records the installation and becomes the current valve at that location. The previous valve is automatically archived.

① Select Position

Customer

Location

Valve Position (Tag #)

Valve Location / Equipment Protected

② New Valve Details

Manufacturer

Model

Serial Number *

Asset ID (Customer)

Valve Type

ASME Code

Cap Type

Inlet Size (in)

Outlet Size (in)

Orifice Letter

Set Pressure (PSIG)

Capacity

Capacity Unit

Body Material

O-Ring Material

Flange Rating

Connection Type

Flange Facing

③ Spring Specification

Spring Number

Range

Material

Spring Verified By

④ Where It Came From

Source Notes

Installation Date

Overdue

4

Due < 30 days

3

Due < 90 days

6

All Upcoming & Overdue Inspections

Priority	Tag #	Location	Customer	Current Valve	Last Inspected	Interval	Days
Overdue	PCU-PC 0317	D-111	ExxonMobil Baytown	Anderson Greenwood	Aug 23, 2021	12 mo	+47d
Overdue	V-493	—	Hogan 1-24H	Ari Reyco	Mar 12, 2024	12 mo	+23d
Overdue	V-202	—	Hogan 1-24H	Ari Reyco	Jan 05, 2024	12 mo	+19d
Overdue	V-203	—	Hogan 1-24H	Ari Reyco	Jan 05, 2024	12 mo	+4d
Due Soon	V-484	Discharge	Bridgewater A	Mercer 9185J11P98U1	Dec 01, 2024	12 mo	12d
Due Soon	V-495	Recycle	Bridgewater A	Mercer 9153H11T84U1	Dec 10, 2024	12 mo	18d
Due Soon	V-494	Discharge	Bridgewater A	Mercer 9144F11P25C1	Dec 20, 2024	12 mo	28d

Work Order · New

1

Position

Select valve location

2

Order Info

PO, release, dates

3

Valve & Spring

Asset details

4

Service Conditions

Media, pressure, temp

5

Pre-Test

3 readings before repair

6

Part Inspection

Condition per part

7

Final Test

Pass readings & stamp

8

Review & PDF

Generate certificate

Select Valve Position

Search by tag number, or browse by customer and site. The current valve installed at this position will be auto-filled.

Tag Number / Search

Original Valve Info

Previous valve at this position

Last Installed Valve Replaced Aug 23, 2021

Manufacturer

Crosby

Model

JQ-3-RV

Serial Number

88244771

Valve Type

Conventional

Set Pressure

306 PSIG

Capacity

1180 GPM

Inlet / Outlet

3" / 4"

Orifice

L

Body Material

Carbon Steel

Trim

Stainless Steel

Flange Rating

300 lb Raised Face

ASME Code

UV

Work Order History at This Position

Date	Work Order	Type	Valve	Pre-Test (PSIG)	Pass Test (PSIG)	Tester	Result
Aug 23, 2021	WO-598441	Annual Inspection	Anderson Greenwood	308 / 307 / 308	310 / 309 / 309	D. Hicks	Pass
Sep 14, 2020	WO-567812	Test Only	Anderson Greenwood	306 / 307 / 306	307 / 307 / 308	Manuel Alvarez	Pass
Sep 02, 2019	WO-541093	Annual Inspection	Anderson Greenwood	305 / 306 / 306	307 / 307 / 306	Arthur Espinoza	Pass
Mar 15, 2018	WO-512774	Pretest / Repair	Crosby JQ-3-RV	309 / 309 / 310	308 / 308 / 308	D. Hicks	Pass

Final Test Results

Record post-repair test results, equipment used, and personnel.

Pass Test 1 (PSIG)

Pass Test 2 (PSIG)

Pass Test 3 (PSIG)

Test Media

Set Pressure (PSIG)

Back Pressure (PSIG)

Relieving Capacity

Valve Tight (% / PSIG)

Blowdown (PSIG)

Back Pressure Tested (PSIG)

Lift

Equipment & Personnel

Test Stand

Test Gauge Serial No.

Calibration Date

Ring Setting — Guide

Ring Setting — Nozzle

Test Date

Assembled By

Tester

Witness

VR Stamp Applied Duplicate Tag: NA

Inspection History — PCU-PC 0317

Current Valve

Anderson Greenwood 42310L34/S

S/N 90123057 · Set 306 PSIG · Pilot

AUG 05, 2025

Pretest / Repair — WO #656284

Seats replaced · Inlet Flange machined · Pass: 311/310/310 PSIG

AUG 23, 2021

Annual Inspection

All parts good · Pass: 308/307/308 PSIG · Last record before swap

SEP 14, 2020

Test Only

Set 306 PSIG · No repair needed

SEP 02, 2019

Annual Inspection

Minor nozzle lapping · Pass: 305/306/306 PSIG

Set Pressure Trend

Pre-test reading 1 over time (PSIG)

↑ Slight upward drift noted — watch set pressure on next inspection.

Valve Swap Log

Date	PM-PAT #	Position	Site	Previous Valve	S/N	New Valve	S/N	Provenance
Nov 06, 2025	PM1953302	V-497	Bridgewater A	Mercer 91-51G11V09U2	1754805	Taylor 825G485131140	118828-8	SOLD NEW
Nov 06, 2025	PM1953860	V-486	Bridgewater A	Mercer 91-62J11T84U1	1700166	Mercer 9162J11T84U1	1310621	From V-496 · Leona 39-25H
Nov 06, 2025	PM1953859	V-484	Bridgewater A	Mercer 91-85J11P98C1	1700161	Mercer 9185J11P98U1	1262069	From V-494 · TUBB 39-21H
Nov 06, 2025	PM1953307	V-302	Hogan 1-24H	Wellmark W9503RS-125	16007224-52	Taylor 825J5711311	134598-3	SOLD NEW
Nov 06, 2025	PM1953332	V-493	Hogan 1-24H	Farris 26KA10-120	908735-7-A10	Ari Reyco R-10KS120	282252-20	From V-304 · Leona 39-25H

Generated Certificates

Certificate	Valve / Position	Customer	Test Date	Generated	Status
WO-656284	PCU-PC 0317 · D-111 Anderson Greenwood 42310L34/S	ExxonMobil Baytown	Aug 05, 2025	Aug 05, 2025	Issued
WO-655931	V-302 Taylor 825J5711311	Exxon Hogan 1-24H	Nov 06, 2025	Nov 06, 2025	Issued
WO-655932	V-486 · Fuel Mercer 9162J11T84U1	Exxon Bridgewater A	Nov 06, 2025	—	Pending

Add your Google Maps API key to enable live map — see source comment

Date	PM-PAT #	Previous (As-Found)	Installed (As-Left)	Provenance
Aug 23, 2021	PM1953100	Crosby JQ-3-RV S/N 88244771 · 306 PSIG	Anderson Greenwood 42310L34/S S/N 90123057 · 306 PSIG	SOLD NEW
Mar 15, 2018	PM1812043	Consolidated 1900 Series S/N 7741233 · 306 PSIG	Crosby JQ-3-RV S/N 88244771 · 306 PSIG	From PCU-PC 0290
